Patented Front Independent Suspension
The Bad Boy Maverick Zero-Turn Mower is equipped with our patented front and rear EZ-Ride® Suspension system. This historic innovation mounts powerful high-performance Hydro-Gear 3200 integrated drives on rubber isolators, allowing the drives to independently absorb bumps and glide effortlessly over uneven terrain. Isolators on the hinged front wheel arms work independently to provide suspension from the front, giving you the smoothest ride around. It's the same system Bad Boy uses on our Outlaw R Series Commercial Mowers, with the same commercial-grade strength.
- Kohler
- 48"/54"/60" - 747cc, 25hp Air-Cooled Confidant ZT740
- Kawasaki
- 48"/54"/60" - 726cc, 24hp Air-Cooled FS730V
- Cutting Widths
- 48"/54"/60"
- Weight
- 48" - 957 lbs. | 54" - 1,005 lbs. | 60" - 1,031 lbs.
- Height / Length
- 47"/80"
- Chute Up / Chute Down Width
- 48" - 54"/61" | 54" - 58"/67" | 60" - 64"/73"
- Suspension
- E-Z Ride® Patented Compression Rear Suspension with Independent Front Suspension Rails
- Transmission
- 3200 Hydro-Gear® 10cc Integrated Transaxle
- Deck Thickness
- 3/16" or 7-Gauge Thick Solid Steel
- Cutting Height
- 1.5" - 4.5" with Deck Height Control System
- Lift & Height Adjustment
- Foot-Assist Manual Lift with Dial-Style Height Adjustment. Optional Electric Lift.
- Rear Tires / Front Tires
- 48" - 23x9-12 Reaper® / 13x6.5-6 Smooth
54"/60" - 23x11-12 Reaper® / 13x6.5-6 Smooth
- Fuel
- 6.5 Gallons, Unleaded Gasoline
- Ground Speed (Forward)
- Up To 9 mph
