| Total Fuel Capacity |
6.5 gallons |
| Drive Tires |
20″ x 10″-10″ |
| Caster Tires |
11″ x 6″-5″ |
| Seat |
Padded with arm rests, adjustment forward and back (tools required) |
|
| Drive System Type |
Hydro-Gear ZT2800 Transaxle |
| Pumps |
Internal Pump: 10 cc |
| Motors |
Internal Motor: 16 cc |
| Forward Ground Speed |
8 mph |
| Reverse Ground Speed |
5 mph |
| Parking Brake |
Hand-activated lever |
| Deck |
| Cutting Widths |
48″ and 52″ |
| Type |
Hero Cutter Deck |
| Cutting Height |
1.5″ to 4.5″ in .25″ increments |
| Deck Lift |
Foot-operated pedal |
| Construction |
Dual-plate cutter deck constructed of 2 steel plates. Reinforcement plate at cutter deck spindles. |
| Spindles |
Aluminum housing with sealed ball bearings. |
| Blade Engagement |
Ogura GT1 (74 ft lb)
Adjustable air-gap for extended life. |
