CC 30 H Riding Lawn Mower
- The Cub Cadet CC30 H is powered by a Briggs & Stratton 344 cc engine with choke-a-matic.
- 30-inch stamped, 14-gauge, single blade side discharge mowing deck with mulch kit included.
- Ideal for mowing up to 1 acre of mostly flat terrain and a few obstacles.
- LED headlight for extended life and enhanced visibility.
- 3-year/120-hour limited residential warranty.
Engine
-
Engine Brand: Briggs & Stratton
- Engine Model Number: 21R707-0152
-
Engine Displacement: 344cc
-
Engine Output: 10.5HP
-
Starter Type: Electric
-
Fuel Tank Capacity: 1.3 gal. US
-
Cylinders: Single
-
Engine Start: Ignition Key
-
Engine Oil Capacity: 1.5 qt. US
-
Lubrication: Fully pressurized
-
Charging System: 3.75 amp regulated
-
Fuel Gauge: No
-
Choke: Choke-a-matic
-
Air Filter: Single element
-
Oil Filter: Yes
-
Fuel Delivery: Carburetor
Battery
-
Battery: 12V 150 cold crank amps
-
Battery Type: AGM (Absorbent Glass Mat)
Drive System
-
Transmission: Hydrostatic, foot
-
Forward Speed: 4 MPH
-
Reverse Speed: 2 MPH
-
Rear Axle: 3/4" w/dual PM steel drive hubs
- Transmission HousingDie-cast aluminum
-
Transmission Type: Hydro-Gear T2HP
-
Engine to Transmission: Hydrostatic, Foot (Hydro-Gear T2HP)
Cutting Deck
-
Deck Cutting Width: 30"
-
Cutting Modes: Discharge/mulch/bagging
-
Deck Wash: Included
-
Deck Material: Steel, 14-gauge
-
Deck Attach/Removal: Removeable
-
Deck Engagement (PTO): Manual lever
-
Deck Construction: Stamped
-
Spindle Construction: Die-cast aluminum spindle housings w/ ball bearings
-
Blade(s): 1
-
Deck Lift: Lever
-
Cutting Height Range: 1.5" - 4"
-
Deck Positions: 5 position
Warranty
-
Warranty: 3-year limited residential warranty
Chassis
-
Frame: Robotically welded
-
Front Axle: Steel/14-gauge
-
Turning Radius: 18"
-
Bumper: Steel tube
-
Rear Tow Hitch: Included
-
Corrosion Protection: Front bumper
Controls
-
Brakes: Automotive-style disc
-
Steering Control: Manual sector and pinion
Comfort
-
Seat Type: 15" high-back seat
-
Seat Suspension: Seat spring
-
Seat Adjustment: Knob
-
Floor Mats: Traction Pad
-
Steering Comfort: Soft Touch steering wheel
Dimensions
-
Weight (approx.:): 340 lbs.
Additional Specifications
-
Mulch Kit: Included
-
Headlight(s): 1 - LED
-
Discharge Chute: Included
-
Cup Holder: Included
-
Reverse Safety Switch: Included
-
Bagger: Optional
- Model Number: 13CC21JDA10
